Pneumatic Mini Slide Units: Compact, Precise, and Efficient Motion Control

MasterMac2000 presents advanced pneumatic mini slide units designed for high-precision industrial applications. Our compact linear motion accessories deliver exceptional performance in space-constrained environments.

Technical Specifications

Key Features

• Compact design
• Precise linear positioning
• Robust construction
• Versatile mounting options

Performance Metrics

• Bore sizes: 12mm to 63mm
• Maximum stroke: 200mm
• Operating pressure: 2-10 bar
• Temperature range: -5°C to 60°C

Product Variants

MQ2-S Slide Unit

• Slim, compact design
• Precision bushings
• Low noise operation
• Medium accuracy applications

MQ2-L Slide Unit

• Linear roller bearings
• Higher load capacity
• Superior precision
• Demanding industrial environments

Technical Features of Pneumatic Mini Slide Units

Our pneumatic mini slide units are engineered to deliver smooth, accurate, and repeatable linear motion in a compact form factor. Key technical features include:

• Compact Design: With bore sizes ranging from 8mm to 25mm and stroke lengths up to 200mm, our mini slide units provide high-force output in a space-saving design, ideal for applications with limited installation space.
• Precision and Repeatability: Manufactured to strict tolerances, our mini slide units ensure consistent and accurate linear motion, essential for precise positioning and control in automation systems.
• Robust Construction: Featuring high-strength aluminium alloy bodies, hard-anodised piston rods, and high-quality seals, our mini slide units withstand the rigours of industrial use, providing long service life and minimal maintenance requirements.
• Integrated Guide and Yoke Plate: Our innovative design combines the slide and yoke plate into a single component, eliminating torsion and misalignment issues, and ensuring extremely precise movements.
• Precise Rolling Bearing Guide: The integrated recirculating ball bearing guide provides smooth, low-friction motion and high load-carrying capacity, ensuring accurate and reliable performance.

Applications of Pneumatic Mini Slide Units in Industrial Automation

Pneumatic mini slide units from MasterMac2000 are extensively used in a wide range of industrial automation applications, offering precision, efficiency, and reliability in space-constrained environments. Some key applications include:

Robotics and Pick-and-Place Systems

In robotic applications and pick-and-place systems, our mini slide units provide precise and rapid linear motion for end-effector positioning, tool changing, and part manipulation. The compact size allows for integration into robotic arms and grippers, enhancing system flexibility and performance.

Pneumatic mini slide units are critical in robotic systems, providing precise linear motion for:

• Robotic arm positioning
• End-effector manipulation
• Tool changing mechanisms
• Sensor alignment
• Compact pick-and-place operations

Characteristics:

• High precision positioning
• Rapid response times
• Minimal backlash
• Compact footprint
• Repeatable motion sequences

Packaging and Material Handling

Mini slide units play a crucial role in packaging and material handling applications, such as carton folding, product sorting, and conveyor control. The fast response times and accurate positioning capabilities ensure efficient and reliable operation, minimising downtime and increasing throughput.

Critical functions in packaging industries:

• Product alignment
• Sealing mechanism control
• Carton folding systems
• Labelling equipment
• Filling and dosing mechanisms

Operational Advantages:

• Smooth, controlled motion
• Precise stroke lengths
• Reduced mechanical wear
• High-speed operation
• Compact design for tight spaces

Electronics and Medical Device Manufacturing

Our mini slide units are used for precise assembly, testing, and inspection requirements in most electronic and medical manufacturing facilities. The compact size and high repeatability enable the automation of delicate processes, improving product quality and reducing manufacturing costs.

Applications in logistics and warehousing:

• Automated sorting systems
• Conveyor belt positioning
• Robotic palletising
• Small parts transportation
• Automated storage retrieval

Key Features:

• High load capacity
• Reliable linear motion
• Robust construction
• Quick response mechanisms
• Versatile mounting options

Enhancing Efficiency and Precision with MasterMac2000 Pneumatic Mini Slide Units

By incorporating MasterMac2000 pneumatic mini slide units into your industrial automation systems, you can achieve significant benefits in terms of precision, efficiency, and reliability:

• Improved Accuracy: The high repeatability and precise motion control provided by our mini slide units enable accurate positioning and assembly, reducing errors and enhancing product quality.
• Increased Productivity: The fast response times and efficient operation of our mini slide units allow for higher machine speeds and reduced cycle times, boosting overall system productivity.
• Reduced Maintenance: The robust construction and high-quality components of our mini slide units minimise wear and tear, reducing maintenance requirements and associated downtime.
• Energy Efficiency: The compact design and efficient air consumption of our mini slide units contribute to lower energy costs and a reduced environmental footprint.

Experience the MasterMac2000 Advantage

When you choose MasterMac2000 for your pneumatic mini slide unit requirements, you benefit from our extensive expertise, commitment to quality, and customer-focused approach. Our team of experienced professionals is dedicated to providing the technical support and guidance you need to optimise your pneumatic systems.

Contact MasterMac2000 today to discuss your pneumatic mini slide unit requirements, request a quote, or explore our full range of pneumatic accessories and cylinders. Let us help you improve the precision and efficiency of your industrial automation applications.
